24-Port PoE+ 2-Port Gigabit RJ-45 Ethernet Switch | UTP3226TS-PSB
- Power over Ethernet (PoE+)
- PoE management
- Support 3 Working Modes through DIP switch
UTP3226TS-PSB provides 24 100M Ethernet RJ-45 downlink ports, 2 Gigabit Ethernet RJ-45 uplink ports and 1 Gigabit combo SFP uplink port. All RJ-45 downlink ports support Power-over-Ethernet (PoE+) and deliver up to 30W power per port. The PoE function can be easily managed via a WEB GUI (http/https).
The switch supports 3 working modes through DIP switch: Default, VLAN and CCTV. Under VLAN and CCTV mode, it supports PoE watchdog features, which can detect and restart the camera automatically if it's frozen. It can be widely used in video security monitoring systems, network projects, etc.
Product Specifications
Downlink Ports |
24*10/100 Base-TX PoE RJ-45(Auto-MDI/MDI-X) |
Uplink Ports |
2*10/100/1000 Base-T RJ-45, 1*1000 Base-X SFP (combo) |
PoE management port |
1* RJ-45 |
Led Indicators |
1*PWR Indicator
|
Cable |
Cat5 or better |
Dimensions (W*D*H) |
442mm*285mm*44mm |
Net Weight |
4.1kg |
Installation |
Rack/desktop/wall mounted |
Material |
Metal shell |
Datasheet
Download Datasheet
