MESILIX UPS Battery Cabinet
XP-RT120BT20
6-10KVA UPS Battery Cabinet dimension is W443*H131*D720mm. It includes battery connection cables, breaker, terminal, etc, with max. capacity of 20pcs 12V/7AH or 12V/9AH batteries inside. The battery connection could be configured to output ±120V.
Battery Installation and Connection
Users need 20pcs batteries, divide into 2groups. Each group has 10pcs batteries in series, as (BAT+ BATN BAT-)shown below. 20pcs batteries installation and connection: There have five battery trays each fit 4pcs batteries, then connect the batteries as shown in below pictures
