Items |
UTP3-GSW1604TS-P200 |
UTP3-GSW2404TS-P420 |
Ethernet Ports |
Downlink Ports |
16*10/100/1000 Base-T PoE RJ-45 (Auto-MDI/MDI-X) |
24*10/100/1000 Base-T PoE RJ-45(Auto-MDI/MDI-X) |
2*1000 Base-X SFP |
|
PoE |
PoE Standard |
IEEE 802.3af/at (PSE) |
IEEE 802.3af/at (PSE) |
PoE Power Supply Type |
End-span |
End-span |
PoE Pin Assignment |
1/2(+),3/6(-) |
1/2(+),3/6(-) |
PoE Power Output |
53.5V DC |
54.5V DC |
PoE Power |
30W max for each port, 175W max |
30W max for each port, 390W max |
Switch Property |
Standards |
IEEE802.3 , IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3X |
Forwarding Modes |
Store and Forward |
Packet Buffer |
4Mbyte |
MAC Table |
8k, support auto learning |
Switching Capacity |
40Gbps / non-blocking |
56Gbps / non-blocking |
Packet Forwarding Rate |
29.8Mpps |
41.7Mpps |
Power Supply |
Input Voltage |
100~240VAC 50/60Hz |
100~240VAC 50/60Hz |
Power Consumption |
200W (Including PoE) |
420W (Including PoE) |
Reliability |
Surge Immunity |
6kV, Standard: IEC6000-4-5 |
ESD Protection |
6kV Contact Discharge, 8kV Air Discharge, standard: IEC61000-4-2 |
Operating Temperature |
-10℃~50℃ |
Storage Temperature |
-40℃~85℃ |
Operating Humidity |
5%~95% (Non-condensation) |
Physical Parameter |
Led Indicators |
1*PWR Indicator |
1*PWR Indicator |
16*Downlink Port Link Indicators |
24*Downlink Port Link Indicator |
16*Downlink Port PoE Indicators |
24*Downlink Port PoE Indicator |
4*Uplink Port Link Indicator |
4*Uplink Port Link Indicator |
DIP Switch |
Default: all ports are free to communicate. |
VLAN: downlink ports are isolated from each other, but can communicate with uplink ports. |
Dimensions (W*D*H) |
442mm*285mm*44mm |
Gross Weight |
5000g±60g |
Net Weight |
3800g±40g |
4150g±50g |
Material |
Metal shell |
Installation |
Rack mounted/desktop/wall mounted |
Certifications |
Certifications |
CE, FCC |
